China China AKS Industrial Ceramic Pressure Sensor Transmitter with Hessmann Connector - Reliable Suppliers & Factory Solutions Manufacturers, Suppliers

Ceramic Pressure Sensors are advanced pressure transmitters that utilize a ceramic pressure core, specifically designed to measure the pressure of a wide variety of liquids, gases, and vapors that are compatible with ceramic materials. Featuring a compact structure, these sensors offer a broad measurement range and multiple output options, making them highly versatile for various applications, As essential devices for pressure measurement, these sensors find their usage in numerous fields, ranging from altitude detection in aerospace to pressure regulation in municipal water networks. Particularly in demanding environments such as high-temperature settings or corrosive atmospheres, traditional pressure sensors may fall short. This is where Ceramic Pressure Sensors excel, providing a reliable solution for tough conditions, Manufactured in China, our ceramic pressure sensors demonstrate outstanding corrosion resistance, exceptional long-term stability, robust overload capability, and remarkable cost-effectiveness. This combination of features makes them a preferred choice among suppliers of industrial automation, process control, level measurement, and consumer electronics. Trust our factory for high-quality ceramic pressure sensing solutions tailored to meet your needs

Product Description

Product Specifications
Measurement Type Gauge / Absolute / Sealed Reference
Pressure Range 0~10MPa~600MPa (customizable per model)
Output Signal 4-20mA, 0-5V, 0-10V
Supply Voltage 24 (12~36) VDC
Accuracy ±0.25%, ±0.5% FS (customizable)
Temperature Range Operating: -40°C to +80°C  |  Storage: -40°C to +125°C
Load Capacity Up to 150% of full scale without damage
Electrical Connection M12×1.5, DIN connector, direct lead wire, hermetically sealed
Process Connection M20×1.5, G1/4, G1/2, NPT1/2 (customizable)
Display Option 4-digit LED or 5-digit LCD (optional)
Protection Rating IP65 / IP67 (depending on housing design)
Key Features
💪 Significantly stronger than stainless steel diaphragms and lasts much longer
💰 Cost less than an equivalent oil-filled stainless steel sensor
🎯 Stand out high accuracy (with precision up to 0.1% or higher)
🛡️ Strong corrosion resistance — withstands acids, bases, salts, and other corrosive media
Temperature measuring resistor responds quickly
📈 Good long-term stability
🔧 Easy to install
Applications
🏭 Industrial Process Control: Pressure monitoring of pumps, valves, and pipelines in chemical and pharmaceutical industries
⚙️ Fluid Power Systems: Hydraulic and pneumatic pressure control for engineering and agricultural machinery
🏥 Medical Equipment: Ventilators, anesthesia machines, and blood pressure monitors
💧 Liquid Level Measurement: Indirectly measure liquid level height of storage tanks and water tanks via pressure measurement
🚗 Automotive Industry: Monitoring oil, fuel, and air pressures within engines and transmission systems
🔬 Corrosive Environments: Chemical plants, water treatment facilities, and food processing where corrosion resistance is essential
Installation & Usage Notes
📐 Mount vertically on the pressure port to avoid stress-induced errors
☀️ Avoid direct sunlight and rain exposure when installed outdoors
In lightning-prone areas, install surge protection and ensure proper grounding
🎛️ Zero and span can be adjusted via internal potentiometers if required (factory pre-calibrated)
🖥️ Compatible with SCADA, DCS, PLCs, and smart instrumentation systems
Frequently Asked Questions (FAQ)
What pressure ranges are available for this sensor?
The sensor supports a pressure range from 0~10MPa up to 600MPa. Custom pressure ranges are available depending on the specific model selected.
What output signal types does this pressure sensor support?
The sensor supports three standard output signals: 4-20mA (current loop), 0-5V, and 0-10V (voltage output). These are compatible with most industrial control systems including PLCs, DCS, and SCADA platforms.
Is this sensor suitable for corrosive media such as acids or chemicals?
Yes. The sensor features strong corrosion resistance and is designed to withstand exposure to acids, bases, salts, and other aggressive chemical media, making it ideal for chemical plants, water treatment, and food processing applications.
What is the protection rating (IP rating) of this pressure sensor?
The sensor is rated IP65 or IP67 depending on the housing design selected. IP67 provides full dust-tight protection and resistance to temporary immersion in water, making it suitable for demanding outdoor or wet environments.
Can the zero and span be adjusted after installation?
Yes. Zero and span adjustments can be made via the internal potentiometers if field calibration is required. The sensor is factory pre-calibrated before shipment, so adjustments are typically only needed for specific application fine-tuning.
What process connection options are available?
Standard process connections include M20×1.5, G1/4, G1/2, and NPT1/2. Custom thread types and fitting configurations are also available upon request to suit specific installation requirements.
