Accuracy Instrument
1 / 2
| Type | Gauge pressure / Absolute pressure | Ingress Protection | IP65 |
| Model Number | PT-2088 | Customized Support | OEM ODM OBM |
| Material | SS304 | Range | 0.1 ~ 0 ~ 100 MPa |
| Accuracy | 0.5% FS (typical) / 0.25% | Protection | IP65 |
| Output Signal | 4-20mA / 0-5V DC / RS485 | Power Supply | 11 ~ 28V DC |
| Operating Temperature | -30℃ ~ 80℃ | Long-term Stability | ±0.3% FS / year |
| Explosion-proof Level | Exia II CT6 | Overload | Twice full scale (or 110 MPa) |
| Application | Machine tools, hydraulic / pneumatic technology, pumps / compressors, mechanical engineering | ||
Used for measuring and controlling flow and pressure in demanding process environments.
Monitors and controls pressure in water treatment processes, including filtration, backwashing, and discharge.
Measures and controls pressure in pharmaceutical processes — reaction vessels, storage tanks, and pipelines.
Applied in mixing, heating, and filling processes to ensure precise pressure management.
Used for pressure measurement in power plants — boilers, turbines, and cooling systems.
The PT-2088 supports both gauge pressure and absolute pressure measurement, covering a wide range from 0.1 to 100 MPa to suit various industrial applications.
The PT-2088 offers multiple output signal options including 4-20mA, 0-5V DC, and RS485. Custom output configurations are also supported upon request.
Yes. The PT-2088 holds an intrinsically safe Exia II CT6 explosion-proof certification, making it fully compliant for use in hazardous locations within the oil, gas, and chemical industries.
The PT-2088 operates reliably within a temperature range of -30℃ to 80℃, making it suitable for both cold-weather outdoor installations and high-temperature industrial processes.
Absolutely. The PT-2088 fully supports OEM, ODM, and OBM customization. Customers can request custom ranges, output signals, housing configurations, and branding to match their specific project requirements.
The PT-2088 offers a typical accuracy of 0.5% FS (with a 0.25% option available) and a long-term stability of ±0.3% FS/year, ensuring consistent and dependable performance over extended periods of use.
